Applications
- AC High Potential testing providing higher current than traditional AC transformers
- Perform GIL/GIS, Cable, Transformer, Motor, Generator high potential testing
- Variable Frequency systems for on-site/field testing Phenix offers
- Ratings from 25 kV to over 1 million Volts, 50 or 60 Hz
- Variable Frequency from 20 to 300 Hz or Variable Inductance systems
- High Q ratings for low input current requirements
- Basic or advanced computerized control options
- Dead tank and insulated cylinder designs
- Series and parallel configurations
- Stand-alone, skid-mounted, and truck-mounted
- Systems for laboratory use and outdoor applications
Applications
- Verify electrical insulation integrity and safety in any type of electrical apparatus
- Perform Dielectric Breakdown Tests, Dielectric Withstand Tests, Insulation Resistance Tests, Partial Discharge Tests Phenix offers
- Ratings from 1 kV to over 1 million volts AC or DC
- Basic or advanced computerized control options
- Rugged design for field, industrial, and laboratory settings
- Stand-alone, modular, truck-, trailer- or container- mounted
- Units integrated with Partial Discharge Detectors
- Stackable DC test sets up to 600 kV DC and custom systems with voltage levels up to 1.5 million volts DC
- Oil insulated or epoxy cast high voltage transformers
